Garmin Gt51M-Thp Dual Transducer Set – Thru-Hull Downvu/Sidevu & Traditional Chirp, 12-Pin [010-01966-11]

Description

GT51M-THP – Stainless Steel Thru-Hull Pair DownVü/SideVü 500 W
(CHIRP 260/455 kHz) Traditional 600 W (Mid-band CHIRP 80-160 kHz)
Transducers with Temp (12-Pin)
This thru-hull transducer pair provides ultra-clear sonar pictures of
objects, structure and fish that pass below your boat. These traditional
CHIRP sonar and CHIRP DownVü/SideVü transducers are optimized for
depth performance and rough conditions.
The CHIRP DownVü/ SideVü elements have a power rating of 500 W per
element (1,500 W total) and operating frequencies of 260/455 kHz. The
traditional CHIRP sonar has a power rating of 600 W and operating
frequencies of mid-band CHIRP 80-160 kHz. It includes a built-in
fast-response temperature sensor. For hull deadrises less than 25 degrees.
GT51M-THP includes a 12-pin port/starboard transducers with stainless steel
stems, fairing blocks, Y-cable, bushings, mounting hardware and installation
instructions. Follow the instructions carefully to avoid damaging your boat.
Compatible Devices:

• GPSMAP® 7607xsv
• GPSMAP® 7608xsv
• GPSMAP® 7610xsv
• GPSMAP® 7612xsv
• GSD™ 25 Premium Sonar Module

Specifications:

• Imagining: Standard/Down/Side
• Chirp: Medium/Non Traditional
• Cable Length (Feet): 5′ + 30′ y-extension
• Temperature: Yes
• Speed Included: No
• Pins: 12
• Mounting Style: Thru-Hull
• Box Dimensions: 6″H x 13″W x 17″L WT: 15 lbs
• UPC: 753759152932

Owner’s Manual (pdf)
