Description
Dual Row Marine LED Light Bar – 8″
SPECS
- Input Voltage: 10-30V DC
- Wattage: 36W (12-3W CREE LEDs)
- Raw Lumens: 2880
- Color Temperature: 6000K
- Beam Pattern: Combo/Flood(90deg)/Spot(8deg)
CONSTRUCTION
- Housing Material: Die-cast Aluminum Housing
- Housing Color: White Coating with UV Inhibitors
- Membrane: Gore™
- Lens Material: PC
- Mounting Bracket: Die-cast Aluminum
- Hole Dimensions: Brackets turned inward – 7.25in
- Brackets turned outward – 9.5in
- Mounting Bolt Drill – .25in
- Electronics: Integrated-Epoxy Encapsulated
- Hardware: Stainless 316
OPERATION
- Operating Temperature: -40degC to +60degC
- Current Consumption: 1.9 amps at 13.8 volts
- IP Rating: IP68
- Protections: Reverse Polarity
Specifications:
- Beam Pattern: Spot-Flood Combo
- Length (Inches): 8″
- Housing: White
- Voltage – Input Range (Volts): 12/24v
- Box Dimensions: 6″H x 6″W x 13″L WT: 3.4 lbs
- UPC: 086429312887
