Description
600W Pure Sine Wave Inverter – 24V
PST Series (120 VAC)
This high efficiency DC-AC inverter converts 24 Volts DC to 600 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. The unit comes with pin-type battery cable lugs. Features include built-in electronic GFCI, overload protection, low battery alarm / shut down, low idle power draw of less than 0.5 Amps. AC power is available from a NEMA-20R GFCI duplex outlet on the front panel. Safety certified to UL standards.
Features:
- High efficiency
- Temperature controlled cooling fan – reduces energy consumption
- Low interference Wide operating DC input range: 21.4 – 33.0 VDC
- Commercial grade design suitable for heavy duty loads, long periods of continuous operation & for emergency back up
- UPC – Universal Protection Circuit: low voltage, over voltage, over temperature, over load and short circuit
- Low idle power draw
- Dual GFCI protected AC outlets
- Optional remote control (sold separately): Model RC-15A
- Comes with pin-type battery cable lugs
- Safety certified to UL standards, FCC compliant
Specifications:
- Input: 24 VDC
- Output: 120 VAC
- Watts: 600 Watts
- Surge: 1000 Watts
- Remote Control: RC-15A sold separately
- Weight: 5.9 (lbs)
- Weight: 2.7 (kg)
- Dimensions: 9.37 x 10.87 x 3.23 (in)
- Dimensions: 238 x 276.2 x 82 (mm)
- Safety: ETL to UL Standards
- Warranty: 2 Year Limited
Applications:
- Service vehicles
- Mobile Offices
- Boats
- Recreation Vehicles, Camping
- Telecommunication
- Field work / Construction sites
- Solar power systems
- Emergency backup power
- Home electronics: TV, VCR, video games
- Computers, printers
Specifications:
- Inverter Cont. Output Wattage: 600w
- Outlet Qty: 2 Duplex GFCI
- Inverter Input Voltage: 24v
- Waveform: Pure Sine Wave
- Box Dimensions: 6″H x 11″W x 14″L WT: 7.2 lbs
- UPC: 622988072161
Owner’s Manual (pdf)
Brochure (pdf)
