Schaefer 704-11 Flat-Base Cheek Block – Aluminum Frame With Delrin Sheave

Description

Series 7 Flat Base/Aluminum Cheek/Delrin Sheave

Delrin™ sheave ensures smooth operation and high safe working load. Stainless steel base distributes loads to a large surface area.

Specifications:

• Sheave Dia. 2-3/8″ (60 mm)
• Max. Line 1/2″ (13 mm)
• Length 4-3/8″ (111 mm)
• Width  2-3/4″ (70 mm)
• Height 1″ (25 mm)
• Fasteners (4) 1/4″ RH (6 mm)
• C/C 3-5/8″ (92 mm)
• C/C (wide end) 2″ (51mm)
• C/C (narrow end) 1-9/16″
• SWL 2250 lbs. (1020 kg)
• Weight Alum. 9.6 oz. (272 g)
