Description
3-3/8″ (85MM) OceanLink® NMEA 2000® Tachometer – 5000 RPM – Black Dial & Bezel
The OceanLink® Tachometer automatically presents all the key data ranging from oil pressure and fuel consumption to operating hours – on a generously proportioned inverted dot matrix digital display. Besides a CAN interface with NMEA 2000® certified and SAE J1939 data protocol it features two inputs for analog sensors. The innovative EasyLink data connection makes the installation easy and cost effective. Satellite instruments for further dynamic measurement values receive updates from the central instrument every 20 msec
Features:
- 1x NMEA 2000® input
- 1x J1939 and analog input
- Reverse polarity protection
- Protection rating IPX5
- Operating temperature range -20 °C / +70 °C
- 12/24V
Specifications:
- Gauge Size: 3-3/8″
- Voltage – Input Range (Volts): 12/24v
- Gauge Type: Tachometer w/System Check
- Box Set: No
- Series: OceanLink
- Box Dimensions: 4″H x 8″W x 8″L WT: 0.85 lbs
- UPC: 7640178720961
Note: This product is supported by the original U.S. manufacturer. In case of a proven defect, returns remain possible under our standard return policy, but resolution may involve direct coordination with the manufacturer.
